65*35*1.25mm NXP Ucode 8 RFID UHF Flexible on-metal label
- Description
- Downloads
➊ Original Strength Factory-Factory Direct Sales, Excellent Prices
➋ International Certifications-ROSH, CE
➌ In-stock, express shipping – Ample inventory, fast delivery
➍ Quality Assurance-Strict Inspection, Premium Quality
➎ No Middlemen-Mixed Wholesale Supported
➏ After-Sales Guarantee Return or Exchange for Quality Issues
Product details
| Physical Features: | |
Model | KLO7048 |
Material | PET/Aluminum Foil/Foam |
Dimensions | 65x35x1.25mm（L x W x T） |
Working Temp | -40~+85℃ |
Survive Temp | -40~+120℃ |
Survival Humidity: | 50±15 %RH |
IP Rating | IP68,test for 5 hours at 1m deep water |
| RFID Features: | |
| RFID Standard | EPC C1G2 (ISO18000-6C) |
| Chip Type | NXP Ucode 8 |
EPC Memory | 128bits |
| TID Memory | 96bits |
Read Range(Fixed Reader) | FCC:15.0m,on metal; ETSI:13.0m,on metal |
Read Range(Handheld Reader) | FCC:8.0m,on metal; ETSI: 6.0m,on metal |
| Other Features： | |
| Data Storage | > 10 years |
| Re-write | 100,000 times |
| Installation | Adhesive |
Support Printer | SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc |
Customization | Logo, barcode/QR code, number printing, encoding, antenna design,etc. |
Package | Reel core inner dimension: 76.2mm/ 3” , 400pcs/roll. |
Application | Metallic container tracking | Equipment&device tracking Warehouse shelf | Automotive components tracking IT asset tracking, etc. |
FAQ
Q1: Could I get a sample before placing an order?
A: Yes, we can offer the sample for you to test. Please let us know your requirements.
Q2: How long is your delivery time?
A: For small orders in stock, we will ship out within 1-2 working days. For large-volume or customised orders, production time varies with order quantity and customer requirements.
Q3: Do you accept OEM orders?
A: Yes. We accept OEM/ODM orders.
Q4: What is your MOQ?
A: It's usually 1000pcs depending on different products.
Q5: What is the plate fee?
A: If you need to customise your size, logo and craft, which is different from our standard process, there may be a plate-making fee.
Q6: How to guarantee the quality of your products?
A1: Strict detection during production and testing 100% before shipment.
A2: Strict sampling inspection on products before shipment and intact product packaging.
